Stärke70 uPVC Windows and Doors
Stärke70 uPVC windows and doors are the perfect answer to the increases in the New Zealand BUilding Code
The Stärke70 uPVC Window and door suite has the perfect combination of volume, performance, and classy aesthetics. Stärke’s manufacturing abilities make it perfect for volume housing, apartment and hotel projects, and with its performance it is the best suite for compliance with new code regulations.
Stärke 70 uPVC windows and doors – the future of joinery in New Zealand.
70mm
Construction depth
1.3 W/m2K
Up to RC2
Safety
Up to 45dB
Sound isolation
41mm
Glazing pocket
Full range
- Fixed windows
- Awning windows
- Tilt & Turn windows
- Open in hinged doors
- Open out hinged doors
- French doors
- Sliding windows and doors
- Stacking windows and doors
STÄRKE70 Sliding & Stacking Windows & Doors
- Up to 2.4m height options available
- 70mm construction depth
- Up to 24mm glazing on both sliders and stackers
STÄRKE70 140mm Sliding Windows & Doors
- Uf 1.3 W/m2K
- Up to 2.64 height options available
- Up to 5.8 width available
- 70mm small construction depth
- 41mm glazing pocket
STARKE 70 WINDOW PHPP DATA TABLE FOR PASSIVE HOUSE PLANNING PACKAGE
| Description | Uf left W/(m²K) | Uf right W/(m²K) | Uf bottom W/(m²K) | Uf above W/(m²K) | Frame width left (m) | Frame width right (m) | Frame width bottom (m) | Frame width above (m) | YGlazing edge left W/(mK) | YGlazing edge Right W/(mK) | YGlazing edge Bottom W/(mK) | YGlazing edge top W/(mK) | Yinstallation left W/(mK) | Yinstallationright W/(mK) | Yinstallation bottom W/(mK) | Yinstallation top W/(mK) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Starke 70 Fixed White | 1.30 | 1.30 | 1.30 | 1.30 | 0.070 | 0.070 | 0.070 | 0.070 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
| Starke 70 Awning White | 1.34 | 1.34 | 1.34 | 1.34 | 0.117 | 0.117 | 0.117 | 0.117 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
| Starke 70 Tilt & Turn White | 1.38 | 1.38 | 1.38 | 1.38 | 0.119 | 0.119 | 0.119 | 0.119 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
| Starke 70 Hinge Door White | 1.43 | 1.43 | 1.43 | 1.43 | 0.147 | 0.147 | 0.147 | 0.147 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
| Starke70 Sliding Door Fixed | 1.37 | 1.62 | 1.34 | 1.34 | 0.056 | 0.055 | 0.056 | 0.056 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
| Starke 70 Sliding Door Operable | 1.62 | 1.52 | 1.52 | 1.56 | 0.055 | 0.145 | 0.145 | 0.145 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
| Starke 70 Fixed Black | 1.34 | 1.34 | 1.34 | 1.34 | 0.070 | 0.070 | 0.070 | 0.070 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
| Starke 70 Awning Black | 1.36 | 1.36 | 1.36 | 1.36 | 0.117 | 0.117 | 0.117 | 0.117 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
| Stake 70 Tilt & Turn Black | 1.47 | 1.47 | 1.47 | 1.47 | 0.119 | 0.119 | 0.119 | 0.119 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
| Starke 70 Hinge Door Black | 1.44 | 1.44 | 1.44 | 1.44 | 0.147 | 0.147 | 0.147 | 0.147 | 0.050 | 0.050 | 0.050 | 0.050 | 0.040 | 0.040 | 0.040 | 0.040 |
For those looking for data to upload to PHPP (Passive House Planning Package), you can download this data here: Starke70 SELtdAcceptedJoinery PHPP Data
Standard Colours
Premium Colours
